APPLICATION

PYUNGIL silicone rubber dead-end insulators for 15~46kV have a stronger self-cleaning function with the high hydrophobicity, compared with EPDM rubber one, and this can eliminate the need of periodical water washing operations. For ultra violet, the silicone rubber is considered as one of the best dielectric materials, which can withstand and endure UV deterioration. Also compared with the porcelain insulator, the PYUNGIL dead-end silicone insulators are light-weighted, easy to handle, breakage-resistant, free from crack and also durable.

The PYUNGIL insulators are composed of three basic parts of fiberglass rod, which guarantees the high tensile strength, silicone rubber weather sheds, having excellent dielectric performance and ultra violet resistant characteristics, and metal end fittings crimped directly on to the fiberglass rod. PYUNGIL silicone dead-end insulators have been designed and tested to meet the requirements of ANSI, IEEE, IEC and CEA LWIWG-01 (91) at Kinectrics Incorporation in Ontario, Canada. The PYUNGIL dead-end insulators are manufactured under the rigid quality compliance of the ISO 9001 quality assurance program.
